And then there's the matter of cracks in airplane wings.
But they don't tell you they are there.
Down in that wing, wedged among sheets of carbon fiber as thin as a fingernail, where it would be impossible to spot an opening even with a microscope, a gap appears. Maybe air was trapped during manufacturing. Maybe the resin cured weird. Maybe a couple of pieces that should have been combined … weren't. Not quite.
From the outside? Perfect. Smooth. Shiny, even.
Inside? A problem that might arise 35,000 feet up.
Seeing those hidden weaknesses before they have become all-too-evident disasters? That's what composite testing is. And, I've got to say, the tech is pretty freaky.
Metal is easy. Well. Easier.
Aluminum failure is predictable, when it fails it fails. Cracks grow slowly. They show up on the surface. You can see them, measure them and track their advances. Metal gives you warning.
Composites? Composites are sneaky.
The Boeing 787 is about half-built from carbon fiber composites. The Airbus A350 goes higher. They are lighter than metal. Stronger in a lot of ways. But it's possible for damage to form between layers — engineers call it delamination — and leave not a trace on the surface.
You can't see it. You can't feel it. You might not know it's there until — well. Except until one day you wished you had learned it sooner.
Okay. So. Ultrasonic testing.
Imagine yourself shouting into a canyon and hearing the echo. What rebounds tells you what is out there.
Same idea. Except the yell is a sound wave way above human hearing. Oh, and the canyon is a small section of airplane wing.
Pulses are sent through the material by a transducer. Those pulses bounce back. Solid composite? Clean echo. Hidden void? Crack? Delamination? The echo changes. Engineers interpret those deviations like a doctor interpreting an ultrasound. Same basic concept, actually.
Modern systems are absurd. Phased arrays — dozens of elements firing simultaneously, beams steered electronically, the entire scan passed through from multiple angles in a single swipe. There are a few that can detect imperfections of less than a millimeter in size. That is the width, roughly, of a pencil lead. Maybe smaller.
Ultrasonics comprise approximately 45 percent of composite examinations. There's a reason.
CT scans are done not just in hospitals. At the heart of these systems, which can blast X-rays through a component from hundreds of different angles and knit the results into a 3D model, is an approach called industrial computed tomography.
The resolution on modern systems? Ridiculous. In some cases, you can actually see the individual carbon fibers. The individual fibers themselves are thinner than a human hair. Essentially what you are doing is viewing this material at a kind of atomic-ish level.
Where ultrasonic gives you echoes, CT comes with the full picture. Voids. Wrinkles in the fiber layers. Foreign objects trapped during manufacturing (it's surprising how often that is the case). Flaws in fiber orientation that might lead to weakness under stress.
Expensive? Yes. Slow? Compared to other methods, yes. But for the parts that matter? Nothing else says it all.
This one's strange. When materials break, they are noisy.
Not noise you can hear. Tiny, high-frequency signals. But they are detected by specialized sensors.
Acoustic emission testing is meant to hear those sounds as they occur. Load a structure up with stress — pretend with all your might that it is really being flown — and if anything starts to crack, even down at damage levels too small for the eye alone to discern, then the sensors can "hear" it.
Different damage sounds different. Matrix cracking has one signature. Delamination has another. The sound of fiber breakage — the bad, end-of-the-world kind — is different yet. Engineers can "hear" what's failing and where it is occurring.
Some planes now have such sensors built in. The structure monitors itself. Wild, right?
Boeing's own quality inspectors had found something amiss on the 787 Dreamliner. Delamination present in the carbon fiber sections right near the tail. Layers separating inside the structure.
The cause? Manufacturing. Workers fitting frames to curved fuselage skin. Not everything fits into place, because individual pieces have natural variations. And a few of the joints had to be shimmed — filled in with thin spacers. When the shims were wrong or missing, fasteners went in anyway. Created stress. Stress created damage.
No planes crashed. Nobody got hurt. Because testing caught it.
The entire 787 fleet had been inspected. Manufacturing processes got fixed. Cost a fortune. Took forever. But the alternative? The alternative is unthinkable.
The next time you step onto a plane — one of those nifty new carbon fiber jobs — just remember this.
Every major component was tested in ways you'll never see. Wing sections swept by ultrasonic waves. X-rays mapping internal structures. Sensors listening for sounds that the human ear could not detect.
Most flaws get caught. Virtually all the problems get solved before the aircraft even leaves the factory. All of that detective work goes on behind walls and is done by engineers who may spend whole careers hunting invisible cracks.
That's how modern aerospace works. Not perfection—perfection's impossible—but relentless verification. Test everything. Trust nothing.
The crack doesn't announce itself.
The right technology manages to find it anyway.
