A deceptively simple element decides if a missile hits its target or if it simply becomes an expensive firework. The nose cone, also known as the radome, has to withstand unimaginable temperatures (capable of vaporizing steel) and also stay as electromagnetically transparent as air. As we launch into hypersonic speeds of over Mach 5, protective shields have become a surprise barrier to using speed as a weapon.
Comprehending the numbers alone is a challenge. The radomes of today can withstand and function normally at intense temperatures exceeding 1500°C, with future systems expected to require survivability above 2,100°C and endure 100-g accelerations. They are also known to maintain their RF transparency over frequency bands from 0.3 to 30 GHz. Despite these challenges, the devices must weigh the absolute minimum and cost no more than the guidance systems they protect. The overlap of extremes has perhaps made the development of a radome the purest form of materials science.
The Silicon Nitride Revolution
Silicon nitride is used for advanced ceramics in missiles. Missiles are not likely to ever reach temperatures of 1,900°C, as this remarkable material will not decompose until around this temperature and is able to maintain structural integrity at 1,400°C. Raw temperature resistance is only part of the story.
The material's dielectric constant is between 7.0 and 9.0, with a loss tangent of less than 0.002 at 1 MHz. This means radar waves can pass through it though not easily. Material scientists go beyond silicon nitride, through controlled porosity engineering. Using these methods the dielectric constant was reduced to 3.3-5.8, which is a great improvement in RF performance. This development demonstrates the extent of Faustian deals involved in extreme engineering, where the flexural strength of dense ceramics drops from 170-596 MPa to 95-445 MPa in porous variants. Every gain demands sacrifice.
The old guard hasn't completely given up. Corning's Pyroceram, a glass-ceramic developed in the 1950s, is still used for applications requiring stability below 700°C. This white body, has very stable dielectric behavior. Also, it does not absorb any measurable water. It's vital for uses like missile guidance where the system moves from storage environments---for example, the desert---to maritime environments. Its success in military applications spawned an unexpected legacy: the same technology that protects anti-aircraft missiles also gave birth to Corningware cookware.
Manufacturing at the Edge of Possibility
The way these ceramic components are made, the process must be extra precise and fundamentally new. Earlier, production of components involved burning out the binder at 500-600°C. Sintering was not at the 1,200-1,500°C used for conventional ceramics but at 1,600-1,650°C for 4 hours. And that's just one part of the story. There are very few manufacturers capable of getting slip casting to work at all. When shrinkage rates exceed 25-35%, a sane person might call for the firing squad. This results in a uniform wall thickness where almost every micron counts.
Gel casting is revolutionizing near-net-shape making. It suffers from only a 16--17% shrinkage after sintering, minimizing the extremely expensive post-processing that can cause flawed parts. The process itself is still somewhat alchemical: mixing systems of methacrylamide and methylenebisacrylamide prepolymers with ceramic powders in ratios of 17-18:1 to obtain 50-55 volume percent ceramic loading.
The process with the highest future potential is additive manufacturing. Digital light processing produces Si₃N₄-SiO₂ ceramics with flexural strengths around 540 MPa. These values are higher than many ceramics processed using traditional techniques. This type of 3D printing enables the manufacture of internal geometries that would make Escher proud. Using transition materials in 3D printing can create a monolithic structure with gradient properties---a unique feature. This structuring also avoids creating interfaces typically observed in graded structures. Digital fabrication can perform all these functions better than traditional methods. In all these ways, it is superior to conventional fabrication.
The Hypersonic Crucible
The laws of physics are unforgiving when you are going Mach 8. The front temperatures of an object experience stagnation (where the airflow begins to diverge), which reaches 1,000 to 1,500°C, with localized regions very likely exceeding 2,000°C. The incoming flow compresses air into a high-pressure shock wave as the flow around the object is disturbed. Most people are somewhat familiar with this phenomenon from high-school science class. Air moves quickly, making a shock wave. The pressure of this shock wave can exceed 10⁷ Pascals and shatter structures in milliseconds.
Equally exacting are the electromagnetic demands. Materials should have a dielectric constant as close to air (1.0) as possible, and loss tangents under 0.05. Any values above these reduce efficiency of the systems transmitting through the radome. To add another layer of complexity, these values tend to shift with temperature, meaning that a material may be suitable at room temp but not when heated. While no materials will have the dielectric properties of air or free space, there are many system trades that can be made to get a system that will function in the needed environment.
The Industrial Champions
Only a small number of companies have the expertise, facilities, and security clearance to compete in this sphere. Mentis Sciences has become the firm of choice for hypersonic work, thanks to its composite radomes designed to withstand temperatures exceeding 1,000°C. Working from their Warner, New Hampshire facility, they are using 17 years of process refinement to build next-gen radomes for several defense programs.
The Future Arrives Unevenly
The structures of metamaterials can yield results no other class of materials can provide. Scientists can use these to miniaturize technologies while achieving improved functionality. For example, metamaterials achieve thickness reductions of 67% to 79% compared with standard structures when applied to frequency-selective surfaces.
Also, the efficiency of transmission---defined here as how much signal passes through compared to the intended amount---exceeds 90% for incident angles up to 80°. In other words, even at sharp angles, these surfaces remain effective. The use of 26-40 GHz is typical in radar applications.
With the hypersonic arms race, we must push our technology and materials to the edge of possibility. The AGM-183 ARRW must operate at speeds greater than Mach 15. Meanwhile, Navy SBIR solicitation N221-043 specifies materials that function up to 2,127°C. Yet, even as we strive to meet these demanding specifications, we are only partly covering the scale of investment needed.
Conclusion: The Impossible Made Routine
To win in modern warfare, one needs an excellent understanding of physics and engineering. The missile radome embodies this truth. As adversary technology becomes ever more sophisticated, and as our own weapons---and their radomes---aspire to higher levels of performance, the humble radome remains a critical enabler.
The future requires not continuous improvement but paradigm shifts. Innovations include functionally graded materials, thermally active materials, and AI-optimized designs. However, we are still bound by the laws of thermodynamics and electromagnetics.
In a realm where results are measured in microseconds and materials science is tested at its limits, the radome has evolved from a simple protective shell into an enabling technology for precision warfare. Its design will shape both individual weapons and the structure of future conflict.
Mentis Sciences: Engineering at the Edge
Among the constellation of defense contractors pushing these boundaries, Mentis Sciences stands apart. Our composite radomes exceed mere specification compliance, they perform better where other technologies would fail. What makes Mentis special is not only that our products have extremely stable RF performance at elevated temperatures, but that we have refined the engineering and fabrication processes over more than two decades to get manufacture parts quickly, reliably and efficiently. We welcome the challenges of making components where extreme temperatures, complex shapes, and electromagnetic specifications intersect. Many manufacturers would walk away. Mentis steps in.
Mentis Sciences is the supplier of choice for defense programs requiring radomes to operate in demanding environments. A company like this earns its reputation one successful flight at a time. Their track record speaks louder than any spec sheet.
Mentis Sciences specializes in composite solutions for high-performance applications. We tackle challenges that most won't contemplate. If we can do it, you can count on Mentis composite---engineered and made in America---to protect what matters from environmental threats that can cripple mission-critical systems. Visit our website at www.mentissciences.com.
